Motors

Aerotech’s “U-channel” and “flat” brushless linear servomotors have proven ideal for robots, actuators, tables/stages, fiber optics/photonics alignment and positioning, assembly, machine tools, semiconductor equipment, electronic manufacturing, vision systems and in many other industrial automation applications. Aerotech linear motors are direct drive and consist of a noncontacting forcer coil and “U-channel” or “flat” rare-earth magnet track. This design eliminates backlash, windup, wear and maintenance issues associated with ball screw, belt and rack and pinion based motion control and positioning systems. The noncontact design of the forcer and magnet track results in a maintenance-free system. Aerotech manufactures a complete line of linear motors to meet the needs of your industrial automation application.

Click here to download the Linear Motor Application Guide. The guide provides the history, principles, types and benefits of linear motors. Click here to view our Linear Motors Brochure – a quick and easy way to compare our complete line of “U-channel” and “flat” linear motors.

Aerotech's rotary motor family addresses the needs of both ultra-precision positioning and high-throughput industrial automation applications. Our motors have among the highest torque to inertia ratios available. Brushless rotary motors feature rare-earth magnets for maximum torque and acceleration in a small package.

Click here for our Motor Sizer, a quick and easy way to determine the correct motor for your application.

13 Results Per Page
  • BLMUC Linear Motor

    BLMUC Series Linear Motor

    The BLMUC linear motor is an ultra-compact "U-channel" motor measuring only 52.0 mm x 20.8 mm in cross section, designed to provide high force in an ultra-compact package.   More >

  • BLMC Linear Motor

    BLMC Series Linear Motor

    Aerotech's "U-channel" BLMC series compact linear motors are only 57.2 mm x 31.8 mm and designed for high force in a compact package.  More >

  • BLM Linear Motor

    BLM Series Linear Motor

    Aerotech's "U-channel" BLM linear motor series are 86.4 mm x 34.3 mm in cross section and have proven ideal for both high-accuracy and high-throughput applications.  More >

  • BLMH Linear Motor

    BLMH Series Linear Motor

    The BLMH series "U-channel" brushless linear servomotors offer over 70% greater continuous output force in the same physical envelope than similar models from other manufacturers. BLMH series motors…  More >

  • BLMX linear motor

    BLMX Series Linear Motor

    The BLMX series "U-channel" brushless linear servomotors offer over 49% greater continuous output force in the same physical envelope than similar models from other manufacturers.  More >

  • BLMF Series Linear Motor

    BLMF Series (Ironless) Linear Motor

    The BLMF linear motor series is designed to provide a lower cost and lower profile alternative to conventional linear motor applications. The BLMFI forcer contains no magnetic material to achieve…  More >

  • BLMFS5 Series Linear Motor

    BLMFS5 Series Linear Motor

    The BLMFS5 linear motor series is designed to provide a higher throughput and lower profile alternative to conventional linear motor applications. This is achieved through a proprietary manufacturing…  More >

  • Brushless Rotary Servomotors

    BM Series Brushless Rotary Motor

    The BM series is Aerotech's high-performance brushless rotary servomotors. The motors feature rare-earth magnets for maximum torque and acceleration in a small package.  More >

  • Brush, Rotary DC Servomotors

    1000 Series Brush DC Servomotor

    The 1000 series motors are high-performance brush-type rotary DC servomotors designed for a variety of general and high-performance motion control applications. Custom mechanical or electrical…  More >

  • Hybrid, Permanent Magnet Motors

    SM Series Stepper Motor

    Aerotech offers seven standard models of hybrid, permanent magnet stepper motors. These motors are well-suited for virtually all applications that employ stepping and/or microstepping drives.  More >

13 Results Per Page
